Main Feature
|
Powerful Multimedia Features
|
|
Fully supports DVB-T2/T, HD MPEG 2, MPEG4,HD H.264, ,1080i,1080p,
|
Photo: JPEG,BMP,PNG
|
|
HD-OUT for multimedia play, standard and high definition output for DVB-T
|
Audio: WMA,MP3,AAC (.wma,.mp3,m4a)
|
|
Auto and manually scan all available TV and radio channels
|
Video: MPEG1,MPEG2,MPEG4,H264,
|
|
Aspect ratio 16:9 and 4:3
|
Motion JPEG (.avi.mpg,.dat,.vob,.div,.mov,.mkv,.mjpeg,.ts,.trp)
|
|
HD-OUT , CVBS, coaxial output
|
NTFS,FAT32,FAT16
|
|
|
Jpeg/Audio combo playback
|
|
Multi-language subtitle output supported
|
|
|
Powerful and highly effective 7-day EPG function
|
Demodulation:
|
|
Supports teletext
|
Terrisal Receiver Standard: DVB-T2/T (EN 302755/EN 300744)
|
|
Parental lock
|
QPSK, 16QAM, 64QAM
|
|
PVR ready function via USB 2.0,Timeshift function
|
FEC: 1/2, 2/3, 3/4, 4/5,5/6,
|
|
Multimedia playback via USB 2.0
|
Guard Interval: 1/4,1/8,1/16,1/32,1/128
|
|
Stores up to 1,000 programs and keeps in memory while power-off
|
FFT Mode: 2K, 8K,32K
|
|
|
|
|
Tuner
|
Demultiplexer
|
|
NMI836
|
Standard ISO/IEC 13818-1; ARIB STB-B10
|
|
IF input frequency: VHF: 174MHz - 230MHz/UHF: 474MHz - 860MHz
|
Input max. bit stream rate: 120Mbps (serial)/15MBps (parallel)
|
|
Bandwith: 6/7/8MHz
|
|
|
Input level: -83dBm
|
Hardware Interface
|
|
Signal input: IEC-type female
|
Indicators: Power, signal lock
|
|
|
IR Receiver: 38KHz
|
|
Decoding
|
USB: USB2.0
|
|
Mpeg transport stream and A/V decoding
|
LED display
|
|
Video standard: MPEG-4 AVC/H.264 HP@L4
|
HD-OUT 1.3
|
|
SCART video model CVBS/RGB (for Europe
|
Loop through output: IEC-type, connector, single tuner
|
|
Aspect ratio: 4:3, 16:9
|
TV SCART 1
|
|
Video resolution: 576i, 576p, 720p,1080i and 1080p
|
Coaxial: RCAX1
|
|
Audio standard: ISO/IEC 14.496-3,, AAC, AAC+
|
Power input Spec.: 90—260V AC 8W max
|
|
Audio mode: mono, dual-channel, stereo
|
|
|
|
|
